Torqeedo
Cruise 12.0 FP TorqLink Pod Drive
- SKU:
- 1283-00
- MPN:
- 48000
- Weight:
- 75.00 LBS
- Shipping:
- $149.00 (Fixed Shipping Cost)
Description
Product description
- High-efficiency pod motor (fixed), 25 hp equivalent
- TorqLink data interface - enables fast data exchange between TorqLink components without a gateway
- Battery connection cable with waterproof battery pole terminals (IP 66) for connecting up to two Power 48-5000
- To operate the Cruise 12.0 with more than two Power 48-5000 batteries, please contact your Torqeedo dealer
- Please note that the engine power is reduced to 6 kW when operating with only one Power 48-5000 battery
Ordering information
- Item number: 1283-00 | EAN: 4260113696637
- Throttle not included - best to use with TorqLink throttle with colour display
- Equipment included: Pod motor (fixed) with TorqLink data communication, cable set (4.5 m, 95 mm2) including main switch and v15/p10k propeller, TorqLink data cable 3 m
- Take a look at our Cruise Info Tool for helpful information
- Warranty: 2 years for non-commercial use
Cruise fixed pod motors are the electric motors of choice for sailboats. All Cruise pods have a built-in GPS with an onboard computer and display with speed and input power, state of charge and remaining range, with a compact, low-drag, and lightweight pylon with advanced helical gear design. Cruise 12.0 FP is a 48-Volt, 25 horsepower-equivalent pod drive perfect for sailboats up to 12 tons.
The Cruise 12.0 FP ships with Torqeedo’s advanced communication system, TorqLink, which allows faster and more accurate data sharing between system components.
Cruise 12.0 FP - Benefits:
- High-efficiency pod drive with 12,000 W input power, equivalent to a 25 HP petrol saildrive
- Pair with Power 48-5000 for best performance and accurate range/runtime functionality
- Hydrogeneration mode: charge your batteries while sailing
- Smaller and lighter than combustion saildrives
- Your choice of TorqLink throttles: TorqLink throttle with color display (1976-00) or throttle sail side mounting (1949-00) recommended
- Minimal impact on sailing speed when optional 1945-00 folding-propeller is installed
- Highest-grade seawater-proof aluminum for long service life, even in the harshest conditions
- Comprehensive galvanic corrosion protection through careful matching of all materials and meticulous isolation of materials with different electrochemical properties - ships with anode set for fresh and saltwater
Specifications
Technical Data Cruise 12.0 FP TorqLink
|
| Cruise 12.0 FP TorqLink |
|---|---|
| Input power in watts | 12,000 |
| Propulsive power in watts | 6,720 |
| Comparable diesel inboards (propulsive power) | 25 HP |
| Comparable diesel inboards (thrust) | 25 HP |
| Maximum overall efficiency in % | 56 |
| Static thrust in lbs* | up to 405 |
| Integrated battery | - |
| Nominal voltage | 48 |
| Final charging voltage | - |
| Total weight in kg | 33.5 |
| Motor weight without battery in kg | - |
| Weight of integrated battery | - |
| Shaft length in cm | - |
| Standard propeller (v = speed in km/h at p = power in watts) | v15/p10k |
| Alternative propeller options | v15/p10k Cruise 10.0 (Folding Propeller) v22/p10k v32/p10k |
| Propeller Guide | |
| Maximum propeller speed in rpm | 1,400 |
| Control | TorqLink throttle** |
| TorqLink | Yes |
| Steering | - |
| Tilting device | - |
| Trim device | - |
| Integrated on-board computer | Yes |
| Stepless forward/reverse drive | Yes |
